Projects / Gear Island and Waterloo Wells Replacement - Stage 2 Investigations

Assessing suitable well locations - Lower Hutt

Overview
Current status
Background

We're assessing possible locations for a new water well in Lower Hutt, focusing on two locations at Hautana Square and Ludlam Park (near the Ludlam Crescent & Massey Avenue intersection), Lower Hutt

Start Date
14/01/2025
End Date
30/03/2025
Contact:

If you have any questions about this work, please contact:

Wellington Water, 04 912 4400

We have now finished physical investigations (drilling and pumping water) on site at both Ludlam Park in Woburn  (in between Massey Ave and Ludlam Crescent) and in Hautana Square, Waterloo, Lower Hutt.

The next steps are to assess the findings from the investigations (i.e. data on the groundwater conditions etc.), to determine which location might be suitable for a new well, based on strict criteria.





Overview



The Waiwhetu Aquifer, located below Wellington’s Harbour and Lower Hutt, is a critical source of water for the Wellington region.



We rely on eight water supply wells to bring this water up to the network and into people’s homes and businesses. These wells are ageing and vulnerable to natural events, including earthquakes, tsunamis, flooding, sea level rise, and saline (seawater) intrusion.



To provide extra resilience, we are investigating possible locations for one additional water well in Lower Hutt. This involves checking ground conditions (using techniques such as potholing, drilling, and testing) and water pipe alignments so we can understand the suitability of possible locations.



We have two preferred locations shortlisted, one at Hautana Square and the other at Massey Avenue in Lower Hutt. We’ve shortlisted these two locations based on a range of criteria, following a robust assessment of 93 locations across Lower Hutt.



Background

The Gear Island and Waterloo wells in Lower Hutt provide approximately 40% of the average annual water supply to the Wellington Region and up to 80% in peak summer periods.

The existing infrastructure is vulnerable to natural events including earthquakes, tsunamis, flooding, sea level rise and saline intrusion. The condition of some of the existing well casings is currently unknown.  The Gear Island wells are estimated to be between 40-50 years old, and the Waterloo wells 30-40 years old. These are nearing the end of their design life of 50 years.

Figure 1 shows the location of existing Knights Road water supply bores circled in yellow and Gear Island bores circled in red. The associated water treatment plants are shown as blue boxes, and the project area is circled in orange.





Figure 1. Project location and existing water supply bores



The Waterloo well extraction network is situated along Knights Road, consisting of eight water supply wells that flow into the Waterloo Water Treatment Plant. An additional three water supply wells (used when required) are in Petone’s foreshore and flow into the Gear Island Water Treatment Plant.



We’ve setup a project to develop and implement replacement wells for the Waterloo treatment plant water supply wells to improve the resilience of this crucial water supply asset and enhance our understanding of the Waiwhetu Aquifer.



Investigating possible locations for two new water wells



An important part of the project is investigating possible locations for new water wells. We have identified two locations that assessments indicate would be good locations for water wells, following a comprehensive review of 93 possible locations across Lower Hutt. The kind of things we take into account when assessing locations include the availability of safe, healthy drinking water, proximity to the Waterloo Water Treatment Plant, and achieving value for money among other factors.

We’re now fully investigating the suitability of these areas. The locations are shown below:





Once the investigations at Hautana Square and Massey Ave are complete, we’ll look into the findings to determine whether these locations are suitable for a new well, based on set criteria.



New water wells to improve resilience, rather than increase amount of water sourced

It’s important to note that any confirmed additional well will not increase the amount of water sourced from the Aquifer, rather it increases overall resilience. To explain this, in normal operations we currently have eight wells operating at maximum capacity during the peak summer period (when water demand is at its highest annually).

By increasing the number of wells we use, we can spread the load, allowing all nine wells to operate at a more sustainable level (i.e. around 80%). This is known in the industry as having greater “redundancy”, or in other words, we’ll have a more resilience and reliable regional water supply.



What are the next steps in the process



Once we have reviewed the findings from the investigations at Hautana Square and Massey Ave, Lower Hutt, we will update residents and stakeholders, and confirm the next steps in the process. At this point, we will be able to confirm whether the two identified locations are suitable for water wells.

Frequently Asked Questions

Why are we doing this work?

  • On behalf of Greater Wellington Regional Council, Wellington Water is improving the resilience of Wellington’s drinking water network by investigating possible locations for an additional water well in Lower Hutt. The investigations provide valuable insight to help determine the suitability of the proposed location(s) of the new well. This involves shortlisting suitable locations, and completing investigations (for example: drilling and pumping water from the aquifer) to determine what area we recommend putting a new well.

  • These investigations are now complete, and we’re now in the process of compiling the data. Once assessed, this analysis will inform the decision on the preferred location for the new well.

  • The project purpose is to develop and implement replacement wells for the Waterloo water supply wellfield to improve the resilience of this crucial water supply asset that supplies much of the Hutt and Wellington City drinking water supply.

Why is it important?

  • The Waiwhetū Aquifer, located beneath Wellington’s Harbour and Lower Hutt, provides 40% of the average annual water supply to the Wellington region, and up to as much as 80% during the peak summer period.

  • The existing infrastructure is aging and vulnerable to natural events. If additional wells are not installed, or the existing ones not replaced, we face an increased risk of water shortages in the future.

What is being investigated?

  • We’re currently investigating potential sites to construct an additional well to provide further resiliency in our water system and allow for gradual replacement of the existing wells.

  • The investigations involve checking ground conditions (using techniques such as potholing, drilling, and testing) and water pipe alignments along Hautana and Penrose streets.

  • The investigations will provide valuable insight to help determine the suitability of the proposed location(s) and enable water pipe alignment design and risk assessment.

Why are we investigating locations for a new well, don’t we have enough already?

  • There are eight water wells along Knights Road, Lower Hutt that bring up water from the Waiwhetū Aquifer to our homes and businesses across the Wellington, Porirua and Hutt Valley region.

  • During the summer period, when regional demand for water peaks, our eight existing wells are operating at 100% capacity. Having an additional well allows us to spread the load.

  • Having an additional well doesn’t mean we are taking more water from the aquifer, it means we are putting less pressure on the existing wells, which are old.

  • Additional wells put us in a better position to support local growth (for example: Population growth). With the population continuing to grow regionally, we need continued investment in bulk water supply.

How many new wells are you installing?

At this point, only one additional new well has been approved and expected to be constructed in the 2025/26 financial year. Over the long term, the existing wells are approaching the end of the serviceable life and need to be replaced.

Will this new well impact the amount of water we receive?

  • This project will design, develop, and implement a programme to replace the existing wells with resilient new well(s). It will not result in any additional water being drawn from the aquifer but will dramatically improve the resilience of the infrastructure.

  • These investigations should not impact the water supply.

When is the investigations on site taking place?

We have now completed the physical investigations on site at Hautana Square, Waterloo and Ludlam Park, Woburn, Lower Hutt. These commenced in December 2024 and concluded in April 2025.

When are you expecting to make a decision on where the new well will be located?

We are now awaiting results of the investigations (i.e. aquifer yield and quality, ground / groundwater conditions and location of services) before making a recommendation on the preferred well location to be constructed. A decision is likely to take a few months as analysis of the results has to be completed first.

Who gave approval to install an additional well at the shortlisted locations?

We have all the required resource consents from Greater Wellington Regional and Hutt City Councils to complete the physical investigations on site at the two shortlisted locations – Hautana Square and Ludlam Crescent. Greater Wellington Regional Council and Hutt City Council provided the required consents and approvals.

Who is leading this project?

Wellington Water are investigating possible well locations on behalf of Greater Wellington Regional Council (GWRC). GWRC are funding the project, as they are responsible for bulk water assets. Hutt City Council own the land where the wells might be located.

Wellington Water (and their contractors) will complete the physical investigations, and provide advice to local and regional council on the recommended solution, based on the investigation findings.

Will we be looking to install even more wells, beyond the additional one we’re currently working on?

Yes, in the long term we are going to have to look into installing more wells. There are a variety of reasons for this. The current wells are ageing and in need of replacement over the next 10-15 years plus.

Population growth is another key driver, which is continually increasing the demand for water. Over the long term, this will create a need for additional wells to match this demand. We will need new wells so that we continue to provide reliable water supply for the region.

Why have we narrowed down to locations in Waterloo and Woburn, Lower Hutt?

The two shortlisted locations are based in these suburbs as they satisfy two key criteria (which formed part of the Multi-Criteria Analysis – MCA): suitability of aquifer conditions and proximity of the existing bulk network (the existing Knights Road wells, and Waterloo Water Treatment Plant).

What are other things you took into account when shortlisting suitable locations?

In addition to the above, we also took into account the following:

  • The need for an above ground headworks in accordance with Tuamata Arowai’s Drinking Water Quality Assurance Rules

  • Proximity to houses/other land uses

  • Achievability

  • Constructability

  • Accessibility

  • Consenting requirements

  • Landowner types

  • Affordability
